Control the multiviewer through Ethernet, RS232 serial port, on screen display (OSD), front panel buttons, or IR remote.
A customized text label can be added for each video window to provide easy input identification (UMD).
Adjustable audio gain with VU level indicators for each input channel.
Switch audio independently of video from connected HDMI sources.
Zoom, pan, and crop the image from any source to focus on key areas.
Fluid, real-time video performance with up to 60 frames per second (fps) in all four quadrants.
Four-channel mixing stereo with 16-, 20-, or 24-bit uncompressed PCM audio.
Inputs: 24-, 30-, and 36-bit xvYCC, sRGB, and YCbCr.
Independent video in to video out resolution.
#4k multiviewer 1080p#
PiP and Custom mode: 2K resolution 2048x1080, HDTV resolutions to 1080p and computer resolutions to 1920x1200.
#4k multiviewer full#
Quad and Full mode: Ultra-HD 4Kx2K resolutions to 3840x2160 (30Hz) and 4096x2160 (30Hz), 2K resolution 2048x1080, HDTV resolutions to 1080p, and computer resolutions to 1920x1200.
Inputs: 2K resolution 2048x1080, HDTV resolutions to 1080p and computer resolutions to 1920x1200.
#4k multiviewer windows#
Layer display windows and adjust transparency of each video source display.
Maintain input aspect ratio if desired-no stretching necessary.
2- and 3-source viewing is possible with this method.
Custom Display Mode: the size, position and selection of any or all windows are customizable.
Quad, Picture in Picture, Full Screen, and Custom display modes.
In picture-in-picture and custom display modes, it supports 2K, 1080p, and 1920x1200 output resolutions. In quad and full screen display modes, the multiviewer supports 4K, 2K, 1080p, and 1920x1200 output resolutions. It is capable of displaying the video signals in quad, PiP, full, or custom mode. Share your knowledge of this product.The SPLITMUX-4K-4RT 4K HDMI Quad Screen Multiviewer allows you to simultaneously display real-time video from four different sources on a single HDMI Ultra-HD 4Kx2K monitor. WARNING : May contain chemicals known to the State of California to cause Cancer and Reproductive Harm. Each Multi-view window parameter is completely customizable including layer priority, window positions, window size, background transparency, border color and border pixel width. This is a powerful Video Graphics Processor in a 1U Rack-mount chassis, with low power consumption of less than 20W. The Video Flux is fitted with two HDMI output ports for showing the Multi-View image on two independently controllable HD/UHD channels simultaneously. For more advanced applications the unit can be easily cascaded and its control daisy-chained to create large and easy to control seamless switching or Multi-View system environments of almost any size. With the Video Flux in 4K UHD Quad mode, the HDMI output will include 4 x full HD signals that will be visible at the 4K display and each of the four full HD signals is presented pixel for pixel on the 4K UHD display without any down scaling or degradation. Switching between any of the non preset inputs will not be seamless and the Video Flux will be a 12 x 2 (16 total inputs, but only 12 at the same time) multi-format presentation matrix switcher. The Video Flux is a multi-format seamless matrix, meaning the product will switch seamlessly between any of the 4 input groups with each group having a preset input. Single Switched Source Single Switched Source The Video Flux's powerful graphic engine enables the three modes of operation to allow multiple combinations of use, f or example:
